Cleanco Compact 45 - Dual Heat Exchanger

49
DUAL HEAT EXCHANGER
REF
PART NO.
DESCRIPTION
NOTES:
1
305-070
Switch, High Limit (250F)
2
315-010
Conduit, Plastic 1/2"
3
325-230
Terminal ring #10 Blue
4
325-240
Terminal 90 Fem. x Screw
5
325-302
Power Lock Terminal Blue
6
325-320
Power Lock Insert
7
330-105
Wire 12 Ga. Yellow
8
400-005
Hex Nut, 1/4 x 20 SS
9
405-600
Clinch Stud, 1/4 x 1 S.S.
10
415-025
LW, 1/4 SS
11
415-125
FW, 1/4 SS
12
475-085
Gasket, 5 3/4" Heat Exch.
13
478-005
Insulation, 1" (By the SQ. FT)
Not Shown
14
263-203
SS Hose Assy - HTEXCH 8"
15
485-100
Copper Coil, 3/8 x 25'
16
490-105
Casing (Dual)
17
555-010
Bulkhead Union SS 3/8 x JIC
18
555-213
Elbow, SS 3/8 x JIC
19
555-164
Drain Cock, 1/4" Brass
20
555-335
Hose Barb 90, 1" Barb x 1" MPT
21
380-232
O ring, Silicone 1/2ID x 5/8OD
