Cleanco Compact 45 - Post Thermal Increase ( P.T.I.)

51
POST THERMAL INCREASE ( P.T.I.)
REF
PART NO.
DESCRIPTION
NOTES:
1
263-046
Hose PTI X Panel 3/8 x 18.5"
2
405-620
CS, 1/4 x 3/4 SS(Hex HD)
3
415-025
LW, 1/4 SS
4
415-125
FW, 1/4 SS
5
490-150
Post Heat Coil
6
551-005
Valve, Press. Limiter - 1200 PSI
7
555-024
Bushing, 3/8 M x 1/4 F
8
555-126
Comp. Tube FTG SS 5/8T x 3/8 NPT
9
555-208
Elbow 90, 1/4" Street Extruded
10
555-214
Elbow 90, 3/8" Street Extruded
11
555-452
Plug, 1/4 MPT Hex
12
555-512
Reducing ADPT, 3/8 FPT x 1/4 MPT
13
555-636
Tee, 1/4" Street Extruded
14
555-640
Tee, 3/8" FPT.
15
572-042
Solution hose, 1/4” Blue Neptune HP
16
580-120
Q.C. 1/4 Female (Open)
17
580-125
Q.C. 1/4 Male (Open)
18
581-015
Crimp Fitting, 1/4 HP Hose – 1/4 MPT SVL
19
572-166
Formed Hose 3” Curved
20
582-009
Elbow 90, 3” x 3”
21A
845-016
Adapter Plate (45 PTI)
21B
845-017
Adapter Plate (47 PTI)
21C
845-018
Adapter Plate (56 PTI)
