CleanMaster Raptor 220 - Machine Dimensions; Specifications

36400-E3-Raptor (04-01)
9
OPERATION
SPECIFICATIONS
MACHINE DIMENSIONS
Model 220
LENGTH 711 mm (28 in)
WIDTH 450 mm (17.7 in)
HEIGHT 1016 mm (40 in)
WEIGHT 44.5 Kg (98 lbs)
SOLUTION TANK CAPACITY 41 L (11 gal)
RECOVERY TANK CAPACITY 38L (10 gal)
SOLUTION PUMP 120 V, 10.2 bar (150psi), 1.04 A
VACUUM MOTORS – 2 x 2 STAGE 2 @120 V, 8.6 A, 1032 W
SEALED WATER LIFT 3810 mm (150 in)
TOTAL POWER CONSUMPTION 120V, 15.0 A, 1800 W
POWER CORDS 1 @ 7.6m (25 ft) 3/12
DECIBEL RATING 3 METERS (10 FT) FROM
MACHINE ON CARPET
<78 db(A)
711 mm
(28 in)
1016 mm
(40 in)
450 mm
(17.7 in)
902 mm
(35.5 in)
