PARTS LIST RAPTOR 220
BASE GROUP
PART # DESCRIPTION QTY.
B-10 6-32 X 1/2 PHXSS 4
B-14 NUT 6-32 HEX SS 4
B-17.6 8-32 X 3/4PHX ZINC 4
B-18.02 NUT 8-32 NYLOK, ZINC 4
B-21 10-32 X 5/16 PHXSS 1
B-23.7 10-32 X 5/8 PHXSS 3
B-28.01 NUT 10-32 HEX ZINC 3
B-28.03 NUT, 10-32 NYLOK ZINK 4
B-32 1/4-20 X 3/4 HEX HD CP 8
B-33.38 1/4-20 X 3 HEX HD CP 1
B-33.4 1/4-20 X 3 3/4 HEX CP 5
B-36.01 NUT 1/4-20 NYLOK ZINK 13
B-38.5 WASHER, 1/4 FLAT CP 10
B-39.5 WASHER, 1/4 INT. STAR 1
B-42 WASHER 9/16 x 1 1/4 FLAT 4
C-02.3 CASTER 3 1/2" 2
C-03.3 CLAMP, HOSE 2 1/4 #32 3
C-04.1 COTTER, HAIRPIN 7/16-9/16 2
• C-06 GASKET, BLOWER/ARLON 1/4" 2
• C-07.3 GASKET,VAC SEAL BASE 1
C-23.8 WHEEL 10" - 1/2"BORE 2
C-59 PUSHNUT FASTNER, 1/2 CAP 2
PART # DESCRIPTION QTY.
C-95 VELCRO, ONE WRAP STRAP 1/2" X 12" 1
D-17 90 ST ELBOW 1/4" NPT 1
D-20.03 ELBOW 90 3/8NPT X -6 SAE 1
E-14 CUFF, 1 1/2SLIP X 1 1/4HOSE 1
F-09 Q/C 1/4" PLUG BR SHUT OFF 1
K-17.3 CLAMP,NYLON CABLE 3/16" 2
K-17.4 CLAMP,NYLON CABLE 1/4" 2
M-0790.5 AXIL, ROD 1/2 ECONO 1
M-0791 AXIL, ROD 1/2 1
M-0791.3 PIVOT, TUBE 3.400" 2
M-0792NH PLATE,VAC MNT SERIES,NO QUIT,NO HTR 1
M-31.17 STANDOFF, 5.7 2.260" 6
M-72 SPACER, QUICK CONNECT 1
M-93 WASHER, .219 X .625 18GA 4
SE-06.7/31 HOSE,3/8NPT X -4SAEFMLSVL 31"LONG 1
SE-06.7/9.5 HOSE,1/4NPTX-6SAEFMLSVL 9.5"LONG 1
SE-12.5/10 HOSE,2" FLEX EXHAUST 10" 2
SJ-40BLK100200210 BASE,BLK DRLD SER NO QT 1
SK-85 HARNESS,BASE C1PVV 1
SK-86 HARNESS,HANDLE C1PVV 1
• SL-004.5 BLOWER,2STG 120V 5.7W/PLUG#11639200 2
• SL-23.7 PMP,DIAPH 150PSI 120V W/WIR&SWITCH 1
• RECOMMENDED STOCK ITEMS
