25 EN
5. When only the green operating lamp is still lit, the battery is fully charged.
6. First disconnect the mains adapter from the mains power and then disconnect the
barrel connector from the charging station.
7. Remove the battery from the charging station.
Attaching the Wall Bracket
PLEASE NOTE!
■ Use the fastening material supplied to hang up the wall bracket. If you are unsure
whether the fastening material supplied is suitable for your wall, seek advice from a
specialist stockist.
■ Hang the wall bracket in a secure and solid place.
■ Before drilling, ensure that there are no pipes or cables behind the intended drilling
point.
1. Place the wall bracket on the wall and mark three drill holes (two at the top and one
at the bottom).
2. Drill holes into the wall and insert wall plugs.
3. Screw the wall bracket onto the wall.
Assembly
Attaching the Suction Hose
• The suction hose is plugged directly onto the suction opening (3).
• All nozzles with the exception of the electrical fl oor nozzle and the turbo upholstery
nozzle can be attached to the suction hose. To do this, follow the instructions in the
following sections.
Attaching / Removing the Electrical Floor Nozzle, the turbo upholstery
nozzle and Articulated Suction Tube
No nozzle adapter is required for the electrical fl oor nozzle, turbo upholstery nozzle and
the articulated suction tube.
• They are plugged directly onto the suction opening (3). The catches must be heard
to engage in place. Attach the electrical fl oor nozzle or the turbo upholstery nozzle
to the articulated suction tube in the same way.
• To detach it, press the release button and pull the electrical
fl oor nozzle, the turbo upholstery nozzle or the articulated
suction tube out at the same time.
09122_DE-EN-FR-NL_A5_V2.1.indb 2509122_DE-EN-FR-NL_A5_V2.1.indb 25 26.03.2019 11:59:0526.03.2019 11:59:05
