APPENDICES
Dimensions (LxDxH)
17.25" x 10.25" x 1.25"
43.8 x 26 x 4.5 cm
Weight
7 lb/4.5 kg dry
12 lb/5.9 kg shipping
Operating Temperature
32–100° F/0–38° C
Humidity
15% to 80%, non-condensing
Power Input Range
Auto-adjusting
100–240VAC; 50/60Hz
Power Consumption
30W typical
Expansion Bus In/Out
Proprietary Network
RJ-45 (2), 115.2kbps, 110kž impedance
Category five twisted-pair cable
80' (24 meters) maximum cable
length between any two PSR1212s,
XAP 800s or XAP 400s
RS-232
DB-9 female
9,600 /19,200/38,400 (default)/57,600
baud rate; 8 bits, 1 stop, no parity
Hardware flow control on (default)/off
Control/Status
DB-25 female A/B (2)
Inputs A/B: active low (pull to ground)
Outputs A/B: Open collector, 40VDC max,
40mA each
+5VDC pins (2) (300mA over-current
protected)
Remote Panels A/B
4-pin push-on terminal block
RS-485 proprietary protocol
Cat five twisted-pair cable
1 pair data, 1 pair power and ground
+15VDC (300mA over-current
protected)
Mic/Line Inputs 1-8
Push-on terminal block, balanced,
bridging
Impedance: 5kž
Nominal Level: adjustable -55dBu,
-25dBu, 0dBu
Maximum Level: -35dBu, -5dBu,
+20dBu
Phantom Power: 24V, selectable
Line Inputs 9-12
Push-on terminal block, balanced,
bridging
Impedance: >10kž
Nominal Level: 0dBu
Maximum Level: 20dBu
Outputs 1-12
Push-on terminal block, balanced
Impedance: 50ž
Nominal Level: 0dBu
Maximum Level: 20dBu
Audio Performance
Conditions: Unless otherwise specified all
measurements are performed with a
22Hz to 22kHz BW limit (no weighting).
Frequency Response: 20Hz to 20kHz
±1dB
Noise (EIN): -126dBu, 20kHz BW,
max gain, Rs=150ž
THD+N: <0.02%
SNR: 80dB re 0dBu, (A-weighted)
Dynamic Range: 100dB (A-weighted)
Crosstalk <-91dB re 20dBu @ 20kHz
channel to channel
Approvals
FCC, CSA, IC, CE, NOM, ACA, SABS,
JATE
Assignable Processing Blocks
Filters:
All pass
Low pass
High pass
Low shelving
High shelving
Parametric EQ
Notch
CD Horn
Crossovers:
Bessel
Butterworth
Linkwitz-Riley
Compressor
Delay adjustable up to 500ms
Matrix Mixing Parameters
32x32 matrix
12 analog in/out
12 expansion bus in/out
8 assignable processing blocks in/out
Auto Mixer Parameters
Number of Open microphones (NOM)
PA Adaptive Mode
First Mic Priority Mode
Last Mic Mode
Maximum # of Mics Mode
Ambient Level
Gate Threshold Adjust
Off Attenuation Adjust
Hold Time
Decay Rate
Microphone Input Configuration
Input Gain Adjust
Mic or Line Level
Phantom Power on/off
Filters
All Pass
Low Pass
High Pass
Notch
PEQ
Mute on/off
Chairman Override on/off
AGC on/off
Auto Gate/Manual Gate
Adaptive Ambient on/off
Set-up Software
