CB780E/CB784E RELAY MODULES WITH VALVE PROVING
750-234 33 32-00150—03
sequence—message H6
(second-line-msg) H6
Diagnostic Info
Device RM78nnx < DI
Device Suffix nnnn < DI
Run/Test Sw. RUN or TEST < DI
Operating Control (OperControl) 1 or 0 < DI
Interlock 1 or 0 < DI
Pilot Valve 1 or 0 < DI
Main Valve 1 or 0 < DI
Ignition 1 or 0 < DI
Low Fire Sw 1 or 0 < DI
High Fire Sw 1 or 0 < DI
Preignition Interlock (PreIgn ILK) 1 or 0 < DI
Pilot Valve/First State Oil
Valve(Valv/Start, V25)
1 or 0 < DI
Jumper 1 INTACT or CLIPPED < DI
Jumper 2 INTACT or CLIPPED < DI
Jumper 3 INTACT or CLIPPED < DI
Amplifier Type (Amp Type) NORMAL or AMP-CHECK or
SHUTTER
DI
Flame Response 0.8s or 3s < DI
Purge Time mm:ss < DI
Manufacturing Code (Mfg Code) nnnn < DI
Software Revision (SW Rev.) nnnn/nnnn < DI
Expanded Annun.
(see Table 12)
Remote Command NONE/HOLD/HF/LF
Table 11. Selectable Messages. (Continued)
Selectable Message
(Second Line)
Display Value
(Second Line)
First Line
Message
