Cleco 48EA Series - Page 15

Page 15
PL12EN-48EA
08/06/2015
EN
Description
1 541480 1 3 Switch Pin
2 266255 1 3 Switch Spring
3 B159V 1 3 Cap Screw - #6-32
4 W115 1 3 Lock Washer
5 1009089 1 3 Housing Pin
6 1091PT 1 3 Steel Ball - 3/16"
7 22598 1 3 O-Ring
8 F900185 1 Switch Actuator
9 207317 2 2 Switch Spring Clip
10 541033 1 2 Reverse Spring
11 541624 1 2 Forward/Reverse Spring
12 F900571 1 2 Start/Reverse Switch
13 207316 1 Switch Holder
14 207322 1 Handle
15 207323 1 Handle Sleeve
16 207325E 1 Connector Sleeve
17 542938 1 Reverse Ring
18 542819 1 Light Ring Assembly
19 541017 1 Handle Retainer Nut
20 524818 1 3 O-Ring
301866-2M 2 meter cable
301866-3M 3 meter cable
301866-4M 4 meter cable
301866-6M 6 meter cable
301866-8M 8 meter cable
301866-10M 10 meter cable
301866-15M 15 meter cable
301904-2M 2 meter cable
301904-3M 3 meter cable
301904-8M 8 meter cable
301904-15M 15 meter cable
301903-2M 2 meter cable
301903-3M 3 meter cable
301903-8M 8 meter cable
301903-15M 15 meter cable
301877-4M 4 meter cable
301877-8M 8 meter cable
301877-10M 10 meter cable
301877-20M 20 meter cable
301877-30M 30 meter cable
301877-40M 40 meter cable
301877-50M 50 meter cable
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "D2": 48EAE Series Handle - Air LB Tool Connector
Ref Number # X
21 1
Tool Cable (Optional Length)
21 1
Inline Swivel Cable (Optional Length)
21 1
Angle Swivel Cable (Optional Length)
Tool Cable Extension (Optional Length)
21 1
Cleco
®
Handle - Air LB Tool Connector
