Cleco 48EA Series - Page 17

Page 17
PL12EN-48EA
08/06/2015
EN
Description
1 17-111 3 6 Pan Head Screw - #4-40 x .19
2 541009 2 2 Wave Washer
3 542244 2 2 Stand Off - 5/16"
4 Table "E1" 1 2 Retaining Ring
5 542588 1 Motor Spacer
6 301761 1 Motor Assembly
7 Table "E1" 1 Transducer Assembly
8 Table "E1" 1 Housing
9 B159X 1 3 Pan Head Screw - #4-40 x 1/4
10 207353 1 Lock Nut
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "E1": 48EA Series Motor - Matrix Tool Connector
Ref Number # X
Cleco
®
Motor - Matrix Tool Connector
Table "E1"
Ref. Description # 48EA15 #
48EA28
48EA41
# 48EA58 #
48EA90
48EA105
48EA135
#
48EA175
48EA230
4 Retaining Ring 1 505306 1 505306 1 505306 ------ ------
Transducer
(unprogrammed)
1 542846-12 1 542846-31 1 542846-48 1 542846-100 1 542846-40
Transducer
(programmed)
1 542846-12P 1 542846-31P 1 542846-48P 1 542846-100P 1 542846-40P
Transducer Capacity 12 Nm 31 Nm 48 Nm 100 Nm 40 Nm
8 Housing 1 207340 1 207340 1 207340 1 207341 1 207341
7
