Cleco 48EA Series - Page 19

Page 19
PL12EN-48EA
08/06/2015
Cleco
®
Motor - Air LB Tool Connector
EN
Description
1 17-111 3 6 Pan Head Screw - #4-40 x .19
2 541009 2 2 Wave Washer
3 542244 2 2 Stand Off - 5/16"
4 Table "E2" 1 2 Retaining Ring
5 542588 1 Motor Spacer
6 301761E 1 Motor Assembly
7 Table "E2" 1 Transducer Assembly
8 Table "E2" 1 Housing
9 B159X 1 3 Pan Head Screw - #4-40 x 1/4
10 207353 1 Lock Nut
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "E2": 48EAE Series Motor - Air LB Tool Connector
Ref Number # X
Table "E2"
Ref. Description # 48EAE15 #
48EAE28
48EAE41
# 48EAE58 #
48EAE90
48EAE105
48EAE135
#
48EAE175
48EAE230
4 Retaining Ring 1 505306 1 505306 1 505306 ------ ------
Transducer
(unprogrammed)
1 542846-12 1 542846-31 1 542846-48 1 542846-100 1 542846-40
Transducer
(programmed)
1 542846-12P 1 542846-31P 1 542846-48P 1 542846-100P 1 542846-40P
Transducer Capacity 12 Nm 31 Nm 48 Nm 100 Nm 40 Nm
8 Housing 1 207340 1 207340 1 207340 1 207341 1 207341
7
