Cleco 48EA Series - Page 21

Page 21
PL12EN-48EA
08/06/2015
EN
Description
1 1011732 1 4 O-Ring
2 800116 1 2 Retaining Ring
3 502983 1 2 Thrust Washer
4 541887 1 Washer
5 542090 1 Ring Gear
6 203749 3 6 Needle Bearing
7 541893 3 6 Planet Gear (21T)
8 542793 1 Planet Carrier
9 541898 1 2 Extension Pinion
10 541044 1 2 Pinion Adapter
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
(T) Teeth
Illustration "F": Single Stage Gearing Assembly
Ref Number # X
Cleco
®
Single Stage Gearing
