Cleco 48EA Series - Page 23

Page 23
PL12EN-48EA
08/06/2015
EN
Description
1 541899 1 3 Slip-On Gear (17T)
2 800116 1 2 Retaining Ring
3 Table "G" 1 2 Thrust Washer
4 203749 6 12 Needle Bearing
5 541894 3 6 Planet Gear (17T)
6 Table "G" 3 6 Planet Gear
7 541888 3 6 Planet Pin
8 542724 2 6 O-Ring
9 541887 1 2 Washer
10 542722 1 Ring Gear
11 Table "G" 1 Planet Carrier
12 Table "G" 1 Planet Cage
13 541044 1 2 Pinion Adapter
14 541898 1 2 Extension Pinion
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
(T) Teeth
Illustration "G": Double Stage Gearing Assembly
Ref Number # X
Cleco
®
Double Stage Gearing
Table "G"
Ref. Description # 48EA(E)28 # 48EA(E)41 # 48EA(E)58
3 Washer 1 502983 1 207303 1 207303
6 Planet Gear 3 541894 (17T) 3 541894 (17T) 3 541897 (20T)
11 Planet Carrier 1 542230 1 542230 1 542233
12 Planet Cage 1 542079 1 542079 1 542099
(T) Teeth
