Cleco 48EA Series - Page 25

Page 25
PL12EN-48EA
08/06/2015
Cleco
®
Double Stage Gearing
EN
Description
1 541210 1 2 Retaining Ring
2 510675 2 4 Thrust Washer
3 541169 1 Cover
4 1010843 1 3 O-Ring
5 541185 1 Washer
6 541167 1 Ring Gear
7 541488 3 6 Needle Bearing
8 541478 3 6 Planet Gear (27T)
9 Table "H" 1 Planet Carrier
10 541492 3 6 Planet Pin
11 Table "H" 3 6 Planet Gear
12 541489 3 6 Needle Bearing
13 Table "H" 1 Planet Cage
14 541045 1 Gear Case (includes Ref. 15)
15 800177 1 3 Needle Bearing
16 207352 1 Retaining Nut
17 541044 1 2 Pinion Adapter
18 541043 1 2 Extension Pinion
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
(T) Teeth
Illustration "H": Double Stage Gearing Assembly
Ref Number # X
Table "H"
Ref. Description # 48EA(E)90 #
48EA(E)105
48EA(E)135
9 Planet Carrier 1 542333 1 542332
11 Planet Gear 3 541474 (17T) 3 541475 (21T)
13 Planet Cage 1 541279 1 541278
(T) Teeth
