Cleco 48EA Series - Page 33

Page 33
PL12EN-48EA
08/06/2015
EN
Description
1 934023 1 Lock Ring
2 934035 1 2 Ball Bearing
3 934021 1 Spacer
4 526942 1 2 Bearing
5 933792 1 1 Bevel Gear Set
6 207295 1 Angle Housing
7 500499 1 2 Needle Bearing
8 934025 1 Output Spindle - 3/8" (includes Ref. 9-11)
9 24499 1 3 Retainer
10 9D6481 1 3 Spring
11 26989PT 1 3 Plug
12 543363 1 Output Spindle - 3/8" (includes Ref. 3-15)
13 1091PT 1 3 Steel Ball
14 WS-371 1 3 Spring
15 LB-370 1 3 Bushing
16 207622PT 1 2 Ball Bearing
17 929177 1 Retainer Nut (includes Ref. 18-19)
18 905084 1 3 O-Ring
19 918163 1 3 Shaft Seal
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "M": 301674 AL3 Attachment (3/8” Square Drive)
301675 AL3 Attachment (3/8” Square Drive)
Ref Number # X
Cleco
®
Angle Head Attachment (Code AL3)
