Cleco 48EA Series - Page 35

Page 35
PL12EN-48EA
08/06/2015
EN
Description
1 207307 1 2 Bearing Retainer
2 19469 1 2 Ball Bearing
3 250497PT 1 3 Retaining Ring
4 526916 1 2 Needle Bearing
5 541694 1 Lock Ring
6 800170 1 2 Needle Bearing
7 510732 1 2 Thrust Washer
8 513000 1 3 Retaining Ring
9 847596 1 3 Thrust Bearing
10 500487 1 3 Needle Bearing
11 510692 1 Retaining Nut (includes Ref. 12)
12 30573 1 3 Seal
13 301923 1 1 Bevel Gear Set
14 301927PT 1 Angle Housing
15 502983 1 2 Thrust Washer
16 510689 1 Spindle - 3/8" (includes Ref. 17-19)
17 24499 1 3 Button
18 9D6481 1 3 Spring
19 26989PT 1 3 Plug
20 541108 1 Spindle - 3/8" (includes Ref. 21-23)
21 1091PT 1 3 Steel Ball
22 WS-371 1 3 Spring
23 LB-370 1 3 Bushing
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "N": 301670 AM3 Attachment (3/8” Square Drive)
301671 AM3 Attachment (3/8” Square Drive)
Ref Number # X
Cleco
®
Angle Head Attachment (Code AM3)
