Cleco 48EA Series - Page 39

Page 39
PL12EN-48EA
08/06/2015
EN
Description
1 515544 1 Split Ring (includes Ref. 2)
2 526483 1 3 Rubber Band
3 847104 1 3 Thrust Bearing
4 544179PT 1 2 Thrust Washer
5 526917 2 2 Needle Bearing
6 510680 1 1 Bevel Gear
7 529246 1 1 Bevel Pinion
8 512552 1 2 Thrust Washer
9 513001 1 3 Retaining Ring
10 259144 1 3 Thrust Bearing
11 510669 1 Retaining Nut
12 24751 1 3 Seal
13 800075 1 2 Retaining Ring
14 207351 1 Lock Nut
15 510691 1 2 Thrust Washer
16 526924 1 Bearing Spacer
17 533983 1 1 Splined Adapter
18 510685 1 Angle Housing (includes Ref. 19)
19 882629 1 2 Needle Bearing
20 510723 1 2 Thrust Washer
21 800168 1 3 Needle Bearing
22 510681 1 Spindle - 1/2" (includes Ref. 23-25)
23 24499 1 3 Button
24 9D6481 1 3 Spring
25 207764PT 1 3 Plug
26 541110 1 Output Spindle - 1/2" (includes Ref. 27-29)
27 1014198 1 3 Steel Ball
28 WS-371-B 1 3 Spring
29 LB-501 1 3 Bushing
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "P": 301824 AH3 Attachment (1/2” Square Drive)
301827 AH3 Attachment (1/2” Square Drive)
Ref Number # X
Cleco
®
Angle Head Attachment (Code AH4)
