Cleco 48EA Series - Page 41

Page 41
PL12EN-48EA
08/06/2015
EN
Description
1 515544 1 Split Ring (includes Ref. 2)
2 526483 1 3 Rubber Band
3 847104 1 3 Thrust Bearing
4 544179PT 1 2 Thrust Washer
5 526917 2 2 Needle Bearing
6 515086 1 Retaining Nut
7 541162 1 2 Needle Bearing
8 800151 1 3 Retaining Ring
9 1013571 1 3 Thrust Bearing
10 500514 1 3 Needle Bearing
11 515083 1 3 Seal
12 800075 1 2 Retaining Ring
13 207351 1 Lock Nut
14 533983 1 1 Splined Adapter
15 510691 1 2 Thrust Washer
16 526924 1 Bearing Spacer
17 529244 1 1 Bevel Pinion
18 515085 1 1 Bevel Gear
19 515088 1 Angle Housing
20 515104 1 2 Thrust Washer
21 525103 1 Output Spindle - 1/2" (includes Ref. 22-24)
22 24499 1 3 Button
23 9D6481 1 3 Spring
24 207764PT 1 3 Plug
25 543365 1 Output Spindle - 1/2" (includes Ref. 26-28)
26 1014198 1 3 Steel Ball
27 WS-371-B 1 3 Spring
28 LB-501 1 3 Bushing
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "Q": 301825 MH4 Attachment (1/2” Square Drive)
301835PT MH4 Attachment (1/2” Square Drive)
Ref Number # X
Cleco
®
Angle Head Attachment (Code MH4)
