Cleco 48EA Series - Page 5

Page 5
PL12EN-48EA
08/06/2015
Cleco
®
48EAE Series Technical Data
48EAE Series Specifications - Air LB Tool Connector
ft-lb Nm ft-lb Nm in mm lbs kg in mm in mm
48EAE15AL3(B) 11.1 15 2.2 3.0 2855 15.7 398 3.8 1.7 1.6 41 0.59 15 3/8"
48EAE28AL3(B) 20.7 28 4.4 6.0 1300 16.2 410 4.1 1.9 1.6 41 0.59 15 3/8"
48EAE41AM3(B) 30.2 41 6.6 9.0 1090 17.3 440 4.3 2.0 1.9 48 0.75 19 3/8"
48EAE58AM3(B) 42.8 58 8.9 12 770 17.3 440 4.3 2.0 1.9 48 0.75 19 3/8"
48EAE58AM4(B) 42.8 58 8.9 12 770 17.3 440 4.3 2.0 1.9 48 0.75 19 1/2"
48EAE90AH4(B) 64.2 87 13.3 18 515 18.5 470 6.6 3.0 2.3 58 0.81 21 1/2"
48EAE105AH4(B) 76.7 104 15.5 21 340 18.5 470 6.6 3.0 2.3 58 0.81 21 1.2"
48EAE135MH4(B) 98.1 133 19.9 27 265 19.1 485 7.3 3.3 2.4 61 0.94 24 1/2"
48EAE175AX6(B) 129.8 176 26.6 36 190 21.6 549 10.2 4.6 2.7 69 1.06 27 3/4"
48EAE230AX6(B) 169.6 230 33.9 46 145 21.6 549 10.2 4.6 2.7 69 1.06 27 3/4"
Model Number
Max.
Speed
(rpm)
Length Weight Head Height
Side to
Center
Tool Range
Max Tq
Min Tq
Ouput
Drive
Size
48EAE Series Tool Memory Parameters - Air LB Tool Connector
Model Number
Max Speed
[RPM]
Max Torque
[Nm]
Torque Cal
[Nm]
Transducer
Type
Angle Cal
[PPD]
Static Current
Factor
[Nm/A]
48EAE15AL3(B) 2855 15 17.9794 542846-12 29.8662 0.6929
48EAE28AL3(B) 1300 28 42.8072 542846-31 65.6023 1.4458
48EAE41AM3(B) 1090 41 50.9609 542846-31 78.0980 1.7212
48EAE58AM3(B) 770 58 77.2838 542846-48 110.2015 2.4287
48EAE58AM4(B) 770 58 77.2838 542846-48 110.2015 2.4287
48EAE90AH4(B) 515 87 158.3540 542846-100 165.6771 3.6514
48EAE105AH4(B) 340 104 156.6510 542846-100 248.0254 5.4662
48EAE135MH4(B) 265 133 199.7300 542846-100 316.2324 6.9694
48EAE175AX6(B) 190 176 231.2227 542846-40 441.5931 9.2456
48EAE230AX6(B) 145 230 228.7037 542846-40 575.9910 12.0595
