Cleco DGD mPro400GC Hardware Description

8 P2174HW-EN 2017-01 en02d441_bedingt.fm, 12.01.2017
Abb. 1-2: Connector Locations
Position Description Position Description
1 System Bus Connector 8 Serial Connector #2
2 Tool Connector 9 Anybus Fieldbus
3 Power Connection 10 Serial Connector #1
4 Mounting Bracket Screw 11 USB ports (2)
5 Mounting Bracket Screw 12 Ethernet Connector #2
6 I/O Connectors 13 Ethernet Connector #1
7 Anybus Fieldbus
1
2
3
13
12
11
10
9
8
7
6
5
4

Cleco DGD mPro400GC Specifications

General

Brand	Cleco
Model	DGD mPro400GC
Category	Controller
Language	English
