4
Step 5
Position the seat so that the Rear-Facing Level
Reference Line appropriate for the child’s
weight is parallel with the ground as shown
in Figure 5.
• If using with an infant under 10 kg (22lb),
position the seat with the more reclined
Reference Line (top line) parallel to
the ground.
• If using with an older child who is over
10 kg (22lb), position the seat with the
more upright Reference Line (bottom line)
parallel to the ground.
Step 6
Route vehicle belt through the Rear-Facing Belt
Path and over both Rear-Facing Belt Lock-offs
and buckle vehicle belt, as shown
in Figure 6.
Position lap portion of inflatable lap/shoulder
belt under both forward Belt Tabs and check
that Crotch Strap is not under the vehicle belt.
Figure 5
Figure 6
