Clek FOONF - Installing Rear-Facing Car Seat with LATCH

15
Step 10
Adjust seat to fit snugly against the vehicle seat
back as shown in Figure 20.
• Pull and hold Rigid LATCH
Adjustment Handle.
• Push car seat firmly into vehicle seat back.
• Release Rigid LATCH Adjustment Handle.
St e p 11
Tighten vehicle belt:
• Switch the lap portion of the inflatable
lap/shoulder belt to the automatic locking
mode by pulling the lap portion of the belt
all the way out by holding the webbing
and pulling upwards, as shown in your
vehicle manual.
• Pull down on lap portion of inflatable
vehicle belt to remove excess slack, as
shown in Figure 21.
• Check that Forward-Facing Belt Lock-off
is all the way open with Lock-tab rotated
completely down and as close to the back
metal support bar as possible, as shown
in Figure 22.
IMPORTANT: NEVER lock or partially close
Forward-Facing Belt Lock-off when using an
inflatable vehicle belt.
2
1
Figure 20
Figure 22
Figure 21
