25
Step 10
Switch the the lap portion of the inflatable
lap/shoulder belt to the automatic locking
mode by pulling the lap portion of the belt
all the way out by holding the webbing and
pulling upwards, as shown in your
vehicle manual.
St e p 11
Tighten vehicle belt to secure the car seat.
• Press down in center of car seat to
depress the vehicle cushion and pull
down on lap portion of inflatable
vehicle belt to remove excess slack,
as shown in Figure 40.
• Check that Forward-Facing Belt Lock-off
is all the way open with Lock-tab rotated
completely down and as close to the
back metal support bar as possible, as
shown in Figure 41.
IMPORTANT: NEVER lock or partially close
Forward-Facing Belt Lock-off when using
an inflatable vehicle belt.
Figure 41
Figure 40
