3
Figure 3
Step 3
If the vehicle seat back is adjustable, make
sure the seat back is locked in a more upright
position. Refer to vehicle owner’s manual for
recommended seat back angle. DO NOT
install or use this car seat while the vehicle
seat back is excessively reclined, as shown
in Figure 2.
Step 4
Place car seat Rear-Facing in the vehicle seat
location selected with Rear-Facing Belt Path
toward vehicle seat back and centered in
seating position as shown in Figure 3.
Step 5
Route vehicle belt through the Rear-Facing
Belt Path and over both closed Rear-Facing
Belt Lock-offs, and buckle vehicle belt, as
shown in Figure 4.
Position lap portion of inflatable lap/shoulder
belt under both forward Belt Tabs and check
that Crotch Strap is not under the vehicle belt.
Figure 2
Figure 4
