30
Reinstalling Cover
1. Place the base frame right side up with
the UAS Connectors pointing toward your
body, as shown in Figure 30.
2. Place the foam pad on the frame, such
that the underside grooves are aligned
with the grooves in the seat frame.
3. Unfasten the seat cover and align it with
the seat frame.
4. Pull the cover over the frame, starting
from the front of the seat (opposite UAS
Connectors), as shown in Figure 31.
toward body
Figure 30
Figure 31
