BNP
®
55 SUCTION BLAST CABINET Page 23
© 2019 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 23350, Rev G, 02/19
WARNING
To access liner-mounting screws the reclaimer
must be removed from the cabinet. 600 cfm
reclaimers weigh about 100 lbs. When removing
and installing the reclaimer it must be
adequately supported and secured to
appropriate lift equipment. Failure to secure
and use proper lift device can result in injury.
7.9.3 Remove the reclaimer mounting bolts and
remove the reclaimer from the cabinet.
7.9.4 Remove the reclaimer inlet-pipe adaptor.
7.9.5 Set the reclaimer top-side-up on a clean, flat,
and level surface.
7.9.6 Remove the bolts and nuts, securing the
reclaimer top and then remove the top (and top liner if
the reclaimer is currently lined).
7.9.7 If the reclaimer is currently unlined, begin at the
installation note preceding Paragraph 7.9.14.
7.9.8 Remove the top liner and cylinder liner: Grind
the tack welds from the bottom of the cylinder liner that
secure the liner to the tube, then slide the cylinder liner
and top liner off the inner tube.
7.9.9 Remove the nuts and washers located along the
right side of the inlet and remove the inlet baffle through
the top of the reclaimer.
7.9.10 Remove the screws holding the inlet-side liner
and inlet-top liner and remove both liners from the
reclaimer inlet.
7.9.11 The wall liner is held in place with self-drill
screws; from the outside of the reclaimer, remove the
screws and lift the wall liner from the top of the reclaimer.
7.9.12 Inner cone liners and cone-ring liners are glued
onto the inner cone. Pull off the liners to remove them.
7.9.13 Remove all old caulking and adhesive from the
weldment.
Installation Note: The numbers in parentheses (-)
shown in Figure 27 and on the following applicable
paragraphs show the recommended order of installation.
When installing the liners, make sure that seams are
aligned. The final assembly must be smooth and free of
protrusions, edges, and gaps. Any edges will disrupt the
air flow, causing wear and affecting the reclaimer’s
media cleaning efficiency.
7.9.14 (1st) Place the cone ring liner on the inside of
the cone-ring; check fit and trim if needed. Refer to the
instructions provided with the adhesive; some adhesives
require it to be applied to both contact surfaces. Apply a
multi-purpose contact adhesive, such as 3M
®
No. 10
neoprene contact adhesive or equal, to the fabric side of
the liner and install the liner. Smooth out the liner to
eliminate air pockets.
7.9.15 (2nd) Place the cone liner in the cone with the
fabric side down, check the fit and trim if necessary.
Apply contact adhesive to the fabric side of the liner and
install the cone liner. Smooth out the liner to eliminate air
pockets.
7.9.16 (3rd) Place the inlet-side liner (rubber side out)
against the side of the inlet housing; center the side
liner and align the front edge of the liner with the front
of the housing. Temporarily clamp the side liner in
place.
7.9.17 (4th) Align the wall-liner cutout with the
reclaimer inlet housing and lower the liner into the
reclaimer. Temporarily insert the baffle bolts though
the liner and reclaimer holes to position that side of the
wall liner. Clamp the wall liner in place, making
adjustments to make sure it is flush with the top of the
reclaimer body and that the inlet-side liner is aligned
with the side-liner cutout. Reposition the inlet-side liner
as needed.
While pushing or clamping the liner against the
weldment, secure the wall liner with self-drilling screws
at each existing hole location. NOTE: To field install a
new, first-time wall liner, use self-drilling screws to
secure it at the seam and an inch or two from the
top and bottom at each quadrant.
7.9.18 (5th) Remove the temporary baffle bolts and
install the inlet baffle by inserting bolts and flat washers
from the inside of the reclaimer and then attach lock
washers and nuts from the outside, leaving the baffle
slightly loose.
7.9.19 Apply silicone caulking on seams between the
cone ring and cone liner, to the seams on the cone ring
and cone, between the cone liner and wall liner, and the
seam on the wall liner. Wipe caulking to even with the
liners. Voids will cause premature wear.
NOTICE
All seams between each liner must be sealed,
and all seams between the liners and reclaimer
weldment must be sealed. Voids will cause
premature wear.
