20. Changing the lamps and fuse.
It is Important that only the correct voltage and
w
attage lamps are used, otherwise the flashing
unit may be damaged. A protective fuse (141) of
the cartridge type is fitted on the push and turn
principle.
Models 2001 and 2002 each contain two 6V
lamps and two 12V quartz-halogen lamps. Model
2
003 contains two 6V lamps only.
The 6V lamps are the slide illuminators and the
12V lamps provide the illumination for promoting
after-images and Haidinger’s brushes.
To exchange a 6V lamp, open lamphousing (127)
and unscrew the faulty lamp (turn anti-
clockwise). The plastic bulb holder can be drawn
from its supporting slide to facilitate lamp
removal.
To exchange a 12V lamp hold the glass with a soft
cloth and ease the lamp carefully upwards.
Warning: The quartz-halogen 12V lamp must
never be touched with uncovered fingers.
Service and Maintenance
Service and maintenance should only be carried out by
one of the following:
The manufacturer’s service personnel,
Recommended agents or
Qualified persons authorised by Clement Clarke
International Ltd.
Technical Manual
A Technical Manual (part no. 1902076) containing
maintenance information and wiring diagrams etc.
for 2000 series Synoptophores, is avaliable from
Haag-Streit UK Limited.
!
