Synoptophore Slides, 3
1
/4” square, are suitable for use
w
ith the following instruments manufactured by
Haag-Streit UK Ltd:
2001 Synoptophore -In current production
2002 Synoptophore -In current production
2003 Synoptophore -In current production
The Slides are photographically produced on
translucent film (some, indicated with* are on
transparent film for use with Haidinger’s Brush), which, in
the case of the coloured ones, are then
hand-painted. They are enclosed between clear plastic
plates and bound in coloured vinyl (non-sticky) Sellotape.
The resulting slides are virtually unbreakable. For easy
identification the slides are bound in different coloured
Sellotape according to their category:
White Binding - original Maddox series
- labelled with prefix ‘A’
Yellow Binding - Stereoscopic Vision series
- labelled with prefix ‘D’
Green Binding - Fusion series
- labelled with prefix ‘F’
Red Binding - Simultaneous Perception series
- labelled with prefix ‘G’ or ‘H’
Blue Binding - Special purpose slides
- labelled with prefix ‘S’
- Mayou Series of 8 slides
Series ‘A’ Maddox Test Series
- White Binding
(Visual angles are approximate
- ‘V’ is Vertical, ‘H’ is Horizontal)
A 1/2 Red Circle ø8˚ in Green Square 12
1
/2˚
A 3/4 Red Circle ø3
1
/2˚ in Green Square 6
1
/2˚
A 5/6 Red Circle ø1
1
/2˚ in Green Square 3˚
A 7/8 Fusion object 7˚ V 9˚ H
A 9/10 Fusion object
A 11/12 Fusion object 1˚ square
A 13/14 Cross (Black) 8˚V 5˚H
A 15/16 Angle Gamma and Arrow Head
A 17/18 Phoria test (Cross in circle)
A 19/20 Phoria test (Scales and Pointers)
A 21/22 Blind Spot test
*On transparent film suitable for use with
Haidinger’s Brush.
Series ‘S’ Special Purpose Slides
- Blue Binding
S 1/2 Animation Slide - Pony and Trap - To be
used with Automatic Flashing Unit set at
ALT (alternating) with light and dark
controls at same number.
S 3/4 After-image Slide - 1 Horizontal Streak
and 1 Vertical Streak, each with central
red fixation mark. These slides have one
matt surface which must be nearest to
the patient.
S 5 Single slide on transparent film of Black
Spot. For use with Haidinger’s Brush.
S6 Alternative After-image slide. Cross.
Mayou Series of 8 Slides
- Blue Binding
(Sold only in the set of 8 slides)
Slide No. 1 15˚ red square with three small squares
in centre
Slide No. 2 15˚ red square with one small square
in centre
Slide No. 3 12˚ red square
Slide No. 4 9˚ red square
Slide No. 5 6˚ red square
Slide A 1˚ rocking horse
Slide B 1˚ ball
Slide C 1˚ boat
Series ‘D’Stereoscopic Vision Series
- Yellow Binding
(Visual angles are approximate
and include the controls)
D 1/2 Bucket (Black and White) 10˚ø
D 3/4 Spears 11˚ V 10˚ H
D 5/6 Swings 11˚ V 7
1
/2˚ H
D 7/8 Wicket 10˚ V 3˚ H
D 9/10 Tennis Net 5˚ V 10
1
/2˚ H
