Clemsa mutan-II - Location of Main Components

2
LOCATION OF MAIN COMPONENTS
Output LEDs
Program
Button
Buzzer +
OUTPUTS PG
1 2 3 4
Antenna
TM 400
CN3
C5
+
IC1
+ C2
Port for
Auxiliary Cards
Auxiliar
y Card
Voltage Selector
Switch
Connection
Terminals
VDR1
230Vac
– +
~ ~
PR1
12-24V
AC/DC
RL4
RL1 RL2 RL3 RL4
Voltage
Selector
Switch
C1
TRF1
RL1
RL2
RL3
–
Connector
12Vac
24Vac
24Vdc
