2 • OPACITY MONITOR MANUAL IM-A-08740-05 •
Revision Control
Documentation Number and Revision Log
This manual is UniControl Inc. document number IM-A-08740-05 dated February 1, 2022.
Manual Revision Date
IM-A-08740-05 12/27/2021
IM-A-08740-04 11/01/2011
Hardware Revision Number
Electronics Unit LED light source
P/N 31180 Light Source Assembly LED light source
P/N 31181 Receiver Assembly LED light source
P/N 27367 Sight Glass Assembly (qty. of 2)
P/N 31726 Purge Air Blower Kit
Current Software Version Release Date
1.23 05/10/2004
Symbols Used in This Manual
The following symbols may be used in this manual to denote certain conditions.
Danger symbol indicates an immanently hazardous situation, which, if
not avoided, will result in death or serious injury.
Warning symbol indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
Caution symbol indicates a potentially hazardous situation, which, if not
avoided, could result in minor or moderate injury.
Caution used without the safety alert symbol indicates a potentially
hazardous situation, which, if not avoided, may result in property damage.
Photo 1 (Front Cover): Electronics/Display Assembly
