Clevo N150RD1 - Removing the Battery

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Locate the battery and remove screws - (Figure 1a).
3. Carefully lift the battery
up in the direction of the arrow (Figure 1b).
4. Remove the battery off the computer (Figure 1c
).
1
2
3
4
Figure 1
Battery Removal
a. Remove the screws.
b. Lift the battery.
c. Remove the battery.
2
a.
b.
4
3
c.
3
1

3. Battery
•2 Screws
