Disassembly
2 - 4 Disassembly Steps
2.Disassembly
Disassembly Steps
The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the Battery:
1. Remove the battery page 2 - 5
To remove the HDD:
1. Remove the battery
page 2 - 5
2. Remove the HDD page 2 - 6
To remove the Optical Device:
1. Remove the battery
page 2 - 5
2. Remove the Optical device page 2 - 10
To remove the Keyboard:
1. Remove the battery
page 2 - 5
2. Remove the keyboard page 2 - 11
To remove the System Memory:
1. Remove the battery
page 2 - 5
2. Remove the system memory page 2 - 12
To remove the M.2 SSD:
1. Remove the battery
page 2 - 5
2. Remove the SSD page 2 - 13
To remove the Wireless LAN Module:
1. Remove the battery
page 2 - 5
2. Remove the WLAN page 2 - 14
To remove the 3G Module:
1. Remove the battery
page 2 - 5
2. Remove the 3G page 2 - 16
To Next Page
