Clevo NP70PNP User Manual

Introduction
Specifications 1 - 3
1.Introduction
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
1.0M HD Webcam
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wi-Fi 6E AX211, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6E AX210, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6 AX201, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 5 Wireless-AC
9462, 1x1 AC Wireless LAN + Bluetooth
Card Reader
MicroSD Card Reader
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for PCIe Gen4 x4 SSD
Interface
One USB 2.0 Port
One USB 3.2 Gen 1 Type-A Port
One USB 3.2 Gen 2 Type-C Port*
*The maximum amount of current supplied by USB Type-C
ports is 500mA (USB 2.0)/900mA (USB3.2).
One Thunderbolt 4**
**The power output of the Thunderbolt 4 port is 5V/3A in AC
mode or 5V/1.5A in DC mode.
One Mini DisplayPort 1.4
One HDMI-Out Port
One Microphone-In Jack
One 2- In-1 Audio Jack (Headphone / Microphone)
One RJ-45 LAN Jack
One DC-In Jack
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Embedded 4 Cell Polymer Battery Pack, 54Wh
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 20V, 9A (180W)
Dimensions & Weight
396.9mm (w) * 262mm (d) * 25mm (h)
2.49kg (Barebone with 54Wh Battery)

Clevo NP70PNP Specifications

General

Brand	Clevo
Model	NP70PNP
Category	Laptop
Language	English
