Clevo P670RG Series User Manual

Disassembly
2 - 6 Removing the Battery
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Remove the SD card cover and screws - (Figure 2a).
3. Carefully lift the bottom case
up in the direction of the arrow and remove it (Figure 2b).
4. The battery will be visible at point on the computer (Figure 2c
).
6
1
2
19
20
21
22
Figure 2
Battery Removal
a. Remove the SD cover
and screws.
b. Remove the screws at
the rear of the computer.
c. Remove the bottom case
to locate the battery.
2
a.
c.
1
3
4
5
13
6
7
8
9
11
12
14
15
10
b.
16
17
18
19
21
22
20
20

1. SD Card Cover
20. Bottom Case
•18 Screws
