Clevo P670RG Series User Manual

Disassembly
Removing and Installing the the M.2 SSD Module 2 - 13
2.Disassembly
Removing and Installing the the M.2 SSD Module
M.2 SSD-1 Removal Procedure
1. Turn off the computer, turn it over, remove the battery (page 2 - 6).
2. The SSD module will be visible at point on the mainboard (Figure 9a).
3. Remove the screw
(Figure 9b)
4. The SSD module (Figure 9c) will pop-up, and you can remove it from the computer.
1
2
3
b.
c.
a.
2
3
1
3

3.SSD Module
•1 Screw
Figure 9
M.2 SSD-1 Module
Removal
a. Locate the SSD.
b. Remove the screw.
c. The SSD module will
pop up.
