Clevo P751ZM - External Locator - Left Side & Rear View

Introduction
1 - 6 External Locator - Left Side & Rear View
1.Introduction
External Locator - Left Side & Rear View
Figure 4
Left Side View
1. RJ-45 LAN Jack
2. USB 3.0 Port
3. USB 3.1 Ports
4. Multi-in-1 Card
Reader
5. Combined eSATA/
Powered USB 3.0
Port
5
1
2 3
Left
4
3
Figure 5
Rear View
1. Vent/Fan Intake
2. HDMI-Out Port
3. Display Ports
4. DC-In Jack
Rear
4
1
2
3
1
3
