Disassembly
2 - 6 Removing the Battery
2.Disassembly
5. Carefully remove screws - (Figure 2b).
6. Lift the battery off the computer (
Figure 2e
).
7. Reinsert the bottom case starting from point as shown (
Figure 2f) to avoid damaging the rear eSATA/USB 3.0
port. Tighten the screws to secure the bottom case in place.
Figure 2
Battery Removal
(cont’d.)
d. Remove the screws.
e. Lift the battery off the
computer.
f. Reinsert the bottom case
and tighten the screws.
To Next Page
