Clevo P870DM Service Manual

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Remove the screws - (
Figure 1a).
3. Carefully lift the bottom case up in the direction of the arrow and remove it (
Figure 1b).
4. The battery will be visible at point on the computer (
Figure 1c).
1
9
10
11
12
Figure 1
Battery Removal
a. Remove the screws.
b. Remove the bottom case.
c. Locate the battery.
2
a.
b.
3
4
5
10
12
6
7
9
c.
10
1
8
11

10. Bottom Case
•9 Screws
