Introduction
1 - 10 Mainboard Overview - Top (Connectors)
1.Introduction
Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. DC-In Jack
2. HDMI Port
3. Mini Display Ports
4. USB 3.1 Gen 2
Type-C Ports
5. TP Connector
6. Keyboard Cable
Connector
7. Microphone-In
Jack
8. Headphone & S/
PDIF Combo
Jack
9. USB 3.0 (USB 3.1
Gen 1) Port
10.Multi-in-1 Card
Reader
11. RJ-45 LAN Jack
11
10
9
7
8
6
5
1
3
4
2
