Disassembly
Removing the CCD 2 - 15
2.Disassembly
Removing the CCD
1. Turn off the computer, turn it over to remove the battery (page 2 - 6).
2. Lay the computer down on a flat surface with the top case up forming a 130 degree angle. Carefully remove the
mylar covers - and screws - .
3. Run your fingers around the inner frame of the LCD panel to lift at points - as indicated by the arrows, and
slightly lift up the outer frame at point as indicated by the arrows, and then run your fingers again around the
inner frame at the lower point as indicated by the arrows (Figure 10a).
4. Remove the LCD front cover (Figure 10b).
1
2
3
4
5
6
7
8
5
b.
a.
9
6
2
1
5
7
8
4
3

9. LCD Front Cover
•2 Screws
Figure 10
CCD Removal
a. Remove rubber and
screws and then careful-
ly release the inner
frame of the LCD panel
at the points indicated by
the arrows.
b. Remove the LCD front
cover.
