Clevo W270EGQ User Manual

1 - 20 3G Module USIM Card Installation
Quick Start Guide
1
3G Module USIM Card Installation
If you have included an optional 3G module in your purchase option (Factory Option for Model A & C Com-
puters Only), follow the instructions below to install the USIM card (which will be provided by your service
provider), and then run the Wireless Manager application. See “Wireless Manager” on page 7 - 35 for instruc-
tions on installing the program etc.
1. Turn off the computer, and turn it over and then remove the battery (slide the latches in the direction indicated
below and slide the battery out).
2. Insert the USIM card (at the rear of the battery compartment) as illustrated below until it clicks fully into position,
and replace the battery.
Figure 1 - 13 - Battery Removal & USIM Card Insertion

USIM Card
Orientation
Note that the USIM
card’s readable side
(with the gold-colored
contacts) should face
upwards as illustrated.

Clevo W270EGQ Specifications

General

Memory Slots	2
Maximum Memory	16GB
Display Size	17.3 inches
Operating System	Windows 7 / 8
Optical Drive	DVD Super Multi
Wireless LAN	802.11 b/g/n
Bluetooth	Bluetooth 4.0
USB Ports	2 x USB 3.0, 2 x USB 2.0
Processor	Intel Core i7-3630QM
Storage	2.5" SATA HDD/SSD
Graphics Memory	2GB
Display Resolution	1920x1080 pixels
Weight	3.0 kg
Audio	High Definition Audio
LAN	10/100/1000 Mbps
Card Reader	Multi-in-1 card reader
Webcam	2.0MP
Battery	6-cell Lithium-Ion
Dimensions	413 x 277 mm
