CLF ARES - 27 CH

WWW.CLF-LIGHTING.COM
17.0
21 CH
Function
Value
Setting
Remark
1
Shutter
000 - 019
020 - 024
025 - 064
065 -0 69
070 -0 84
085 - 089
090 - 104
105 - 109
110 - 124
125 - 129
130 - 144
145 - 149
150 - 164
165 - 169
170 - 184
185 - 189
190 - 204
205 - 209
210 - 224
225 - 229
230 - 244
245 - 255
Shutter closed
Shutter open
Strobe 1 (fast → slow)
Shutter open
Strobe 2: opening pulse (fast → slow)
Shutter open
Strobe 3: closing pulse (fast → slow)
Shutter open
Strobe 4: random strobe (fast → slow)
Shutter open
Strobe 5: random opening pulse (fast → slow)
Shutter open
Strobe 6:random closing pulse (fast → slow)
Shutter open
Strobe 7: burst pulse (fast → slow)
Shutter open
Strobe 8: random burst pulse (fast → slow)
Shutter open
Strobe 9:sine wave (fast → slow)
Shutter open
Strobe 10: burst (fast → slow)
Shutter open
2
Dimmer
000 - 255
0 - 100%
3
Fixture
control
settings
000 - 039
040 - 044
045 - 049
050 - 054
055 - 059
060 - 064
065 - 069
070 - 074
075 - 089
090 - 094
095 - 099
100 - 104
105 - 109
110 - 114
115 - 119
120 - 124
125 - 129
130 - 134
135 - 139
140 - 144
145 - 149
150 - 154
155 - 159
160 - 164
165 - 169
170 - 174
175 - 179
180 - 184
185 - 189
190 - 194
195 - 199
200 - 239
240 - 244
245 - 249
250 - 255
No function
1
SILENT MODE (level 1)-70% fan speed
1
SILENT MODE (level 2)-40% fan speed
1
SILENT MODE (level 3)-20% fan speed
No function
1
Fan mode FULL
1
Fan mode REGULATED
1
Fan mode SILENT
No function
1
Calibrated color output mode- COLOR CALIB = ON
1
output mode - = ON
1
Raw color mode- COLOR CALIB = OFF
No function
1
Normal dimming, speed of changes unrestricted
No function
1
Smooth dimming, speed of changes restricted slightly
No function
600 Hz Refresh rate
1200Hz Refresh rate
2400Hz Refresh rate
4800Hz Refresh rate
No Function
1
WDMX - ON
No Function
1
WDMX - OFF
No Function
1
WDMX - RESET
No Function
1
Led power(Normal mode)
1
Led power(Theater mode)
1
Led power(High mode)
No Function
2
DMX
No Function
illuminate display
Manual calibration Manual calibration
Manual calibration mode
1
Value must be held for 3
seconds to activate.
2
Please refer the page 10.
(calibrate by DMX
control) Value must be
held for 3 seconds to
activate.
4
Red 1
000 - 255
LED block 1 - Red 1 (0-100%)
5
Green 1
000 - 255
LED block 1 - (0-100%)Green 1
6
Blue 1
000 - 255
LED block 1 - 1 (0-100%)Blue
7
White 1
000 - 255
LED block 1 - 1 (0-100%)White
8
Red 2
000 - 255
LED block 2 - Red 2 (0-100%)
