Onboard control menus
NO.
Main Menu
Menu level 2
Menu level 3
Remark
1
DMX ADDRESS
<001>
Default 001
2
CONTROL MODE
4CH / 9CH /
11CH / 16CH /
21CH / 27CH /
30CH
Default : 11CH
3
STATIC COLOR *
Dimmer
0-100
Default : 000
Red
0-100
Default : 000
Green
0-100
Default : 000
Blue
0-100
Default : 000
White
0-100
Default : 000
Strobe
0-20
Default : 000
4
PERSONALITY
FANS
REGULATED
Default : REGULATED
SILENT Level (1-3)
FULL
Led power
High
Default : Normal
Normal
Theater
Dimmer Speed
Normal
Default : Normal
Smooth
KEY-Lock
ON/OFF
Default : OFF
W-DMX
ON
Default : ON
OFF
RESET
Calibration
NO CALIBRATION
Default : FACTORY
MANUAL
FACTORY
Refresh rate
600/1200/2400/4800
Default : 600
LCD brightness
Level (1 - 10)
DMX HOLD
DMX HOLD
Default : DMX HOLD
NO DMX HOLD
5
AUTO *
AUTO(1 - 20)
Speed 0 20-
Default : AUTO :1,Speed: 0
6
INFO
Software type
V .X XX
Usage time
TOTAL Xxxx hours
RESET
Use time reset(password)
Temperature
XXX℃
7
FACTORY SET
LOAD
8
MANUAL CALIB
Red
0-255
Default : 255
Green
0-255
Default : 255
Blue
0-255
Default : 255
