CLF ARES - Page 22

WWW.CLF-LIGHTING.COM
20.0
27 CH
Function
Value
Setting
Remark
9
CCT
000 - 009
010 - 255
No function
10000K - 2500K
10
Red 1
000 - 255
LED block 1 - Red 1 (0-100%)
CH 5 must activated
11
Green 1
000 - 255
LED block 1 - (0-100%)Green 1
CH 6 must activated
12
Blue 1
000 - 255
LED block 1 - 1 (0-100%)Blue
CH 7 must activated
13
White 1
000 - 255
LED block 1 - 1 (0-100%)White
CH 8 must activated
14
Red 2
000 - 255
LED block 2 - Red 2 (0-100%)
CH 5 must activated
15
Green 2
000 - 255
LED block 2 - (0-100%)Green 2
CH 6 must activated
16
Blue 2
000 - 255
LED block 2 - 2 (0-100%)Blue
CH 7 must activated
17
White 2
000 - 255
LED block 2 - 2 (0-100%)White
CH 8 must activated
18
Red 3
000 - 255
LED block 3 - Red 3 (0-100%)
CH 5 must activated
19
Green 3
000 - 255
LED block 3 - (0-100%)Green 3
CH 6 must activated
20
Blue 3
000 - 255
LED block 3 - 3 (0-100%)Blue
CH 7 must activated
21
White 3
000 - 255
LED block 3 - 3 (0-100%)White
CH 8 must activated
22
Red 4
000 - 255
LED block 4 - Red 4 (0-100%)
CH 5 must activated
23
Green 4
000 - 255
LED block 4 - (0-100%)Green 4
CH 6 must activated
24
Blue 4
000 - 255
LED block 4 - 4 (0-100%)Blue
CH 7 must activated
25
White 4
000 - 255
LED block 4 - (0-100%)White 4
CH 8 must activated
26
Auto
program
000 - 009
010 - 019
020 - 029
030 - 039
040 - 049
050 - 059
060 - 069
070 - 079
080 - 089
090 - 099
100 - 109
110 - 119
120 - 129
130 - 139
140 - 149
150 - 159
160 - 169
170 - 179
180 - 189
190 - 199
200 - 255
No function
Auto program 1
Auto program 2
Auto program 3
Auto program 4
Auto program 5
Auto program 6
Auto program 7
Auto program 8
Auto program 9
Auto program 10
Auto program 11
Auto program 12
Auto program 13
Auto program 14
Auto program 15
Auto program 16
Auto program 17
Auto program 18
Auto program 19
Auto program 20(Auto program 1-19 cycle)
27
Speed
000
1-255
No function
AUTO Speed or Dimmer Speed
