Clifford Matrix RS2 - Remote Start Harness (H3) Wire Connection Guide

16
©
2001 Directed Electronics, Inc.
Remote Start Ribbon Plug-In Harness
___
___
___
___
___
Remote Start Harness (H3) Wire
Connection Guide
___
___
___
___
___
___
H3/1 BLUE (-) Status/Factory Security Rearm Output
This wire supplies a 200mA output as soon as the module begins the remote engine starting process.
It can be used with a relay to disconnect a sensor from the system as shown below. The H3/1 BLUE
wire can also be used to rearm a factory anti-theft system when the remote engine starting system
shuts down. (See the Feature Descriptions section of this guide.) To bypass an optional sensor:
BLACK/WHITE (-) Neutral Safety Switch Input
VIOLET/WHITE Tachometer Input Wire
BROWN (+) Brake Switch Shutdown Wire
GRAY (-) Hood Pinswitch Input, Zone 1
BLUE/BLACK (-) 200 mA Optional Third Ignition Output
BLUE (-) 200 mA Status/Factory Security Rearm Output
H3/1
H3/2
H3/3
H3/4
H3/5
H3/6
PURPLE (-) 200 mA Starter Relay Turn-On
ORANGE (-) 200 mA Accessory Relay Turn-On
PINK (-) 200 mA Ignition Relay Turn-On
YELLOW (+) Ignition Input to Remote Start
RED (+) Constant Power
1
2
3
4
5
