Clint TCW 42 User Manual

3 4 5
CV
KH
YC
7
YF
1
MV
MP
FCA
SB1 SB2
KRX
6 2 X
PCB
R1 R2
FCM
KH
LPE N
Q1
1 3
2 4
21 11
1222
TV
M M
6 1
L
A1
A2
A2
A1
230V-50Hz
Unit for system with 4 pipes, with
two valves, or with 2 pipes, with or
without valve and electric heater,
with DRA control panel.
PE L N
N L
230 Vac
~230 V 50 Hz
Min Med Max
1
3
2 4
Q1
SM
Unit for system with 2 pipes, with
or without valve, with DRA control
panel.
2.7 Conexiuni electrice
UNITATE PENTRU SISTEME CU 2 SAU 4 TEVI: MODELELE 42÷54
2.7 Electrical connections
Before performing any work on the electrical part of the unit, turn off the
main switch. Always remember to connect the earth wire.
Earth connection is obligatory by law.
The installer must provide for it via the terminal marked with the interna-
tional earth symbol.
UniT FoR 2 AnD 4 pipes sysTem: moDels 42÷54
Main layout: the variants made in the constructions can involve modifi -
cations. Always refer to the layout supplied with the product.
N L
Unit for system with 2 pipes, with
or without valve, with DRM con -
trol panel.
PE L N 3 4 5
16 17 18
N L
230 Vac
SM
~230 V 50 Hz
Min Med Max
1
3
2 4
Q1
min
med
max
viteza minima / minimum speed
viteza medie
/
medium speed
viteza maxima
/
maximum speed
CV Condensator /
Condenser
FCA Siguranta automata /
Automatic protection
FCM Siguranta manuala /
Manual protection
KH Relee de alarma /
Alarm relais
L Faza / Phase
MP
Motor pompa evacuare condens
Drain pump motor
MV Motor ventilator /
Fan motor
N Nul /
Neutral
PCB
Tablou electronic /
Electronic board
PE
Impamantare /
Ground
Q1 Protectie /
Protection
R1/R2 Baterie electrica /
Electric heater
SB1/SB2 Sonda nivel apa /
Water level sensor
SM Sonda temp. minima apa /
Sensor min. water temp.
TV Autotransformator /
Autotransformer
X Bloc terminal /
Power terminal block
YC Vana cu 3 cai (4 T) / 3-way valve (4 T)
YF Vana cu 3 cai / 3-way valve
Inainte de efectuarea oricaror operatii pe partea electrica,
deconectati-va de la sursa principala de energie prin actionarea
intrerupatorului general. Conectati intodeauna cablurile pentru
impamantare.
Impamantarea este obligatorie prin lege.
Instalatorul trebuie sa utilizeze terminalul cel mai apropiat care este
marcat cu simbolul international pentru impamantari.
Schema de montaj: aceasta varianta furnizata din fabrica poate sa
contina modificari. Utilizati intotdeauna schema livrata cu produsul
achizitionat.
Unitate pentru sisteme cu 4 tevi cu
doua vane, sau sistem cu 2 tevi, cu
sau fara vane, cu panou de
comanda DRA.
Unitate pentru sisteme cu 2 tevi, cu
sau fara vane, cu panou de
comanda DRA.
Unitate pentru sisteme cu 2 tevi, cu
sau fara vane, cu panou de
comanda DRM.
BLOC TERMINAL
BLOC TERMINAL
BLOC TERMINAL
