CLIVET DUCT-SL 2 Series - Page 39

Specifications
 Page 39 
ID2-XY 70M+MC2-Y 70M
INDOOR
AIRFLOW
(CMH)
OUTDOOR
DB(℃)
ID WB
(℃)
16.0 18.0 19.0 22.0
ID DB
(℃)
23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0
1248
-15
TC 7.68 7.77 7.86 7.95 8.06 8.06 8.06 8.15 8.26 8.26 8.26 8.26 8.79 8.79 8.79 8.79
S/T 0.75 0.86 1.00 1.00 0.59 0.70 0.80 0.98 0.51 0.61 0.71 0.81 0.33 0.42 0.52 0.62
PI 1.52 1.52 1.52 1.52 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51
-10
TC 7.63 7.72 7.81 7.90 8.02 8.02 8.02 8.10 8.22 8.22 8.22 8.22 8.76 8.76 8.76 8.76
S/T 0.76 0.86 1.00 1.00 0.59 0.70 0.81 0.98 0.51 0.61 0.72 0.82 0.33 0.43 0.52 0.62
PI 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51
-5
TC 7.59 7.68 7.77 7.85 7.99 7.99 7.99 8.07 8.19 8.19 8.19 8.19 8.73 8.73 8.73 8.73
S/T 0.76 0.87 1.00 1.00 0.59 0.70 0.81 0.99 0.52 0.61 0.72 0.82 0.33 0.43 0.53 0.62
PI 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51
0
TC 7.55 7.64 7.73 7.82 7.96 7.96 7.96 8.04 8.17 8.17 8.17 8.17 8.73 8.73 8.73 8.73
S/T 0.76 0.87 1.00 1.00 0.60 0.71 0.81 0.99 0.52 0.62 0.73 0.82 0.33 0.43 0.53 0.63
PI 1.52 1.52 1.52 1.52 1.51 1.51 1.51 1.51 1.52 1.52 1.52 1.52 1.52 1.52 1.52 1.52
5
TC 7.51 7.60 7.69 7.78 7.93 7.93 7.93 8.01 8.14 8.14 8.14 8.14 8.72 8.72 8.72 8.72
S/T 0.77 0.88 1.00 1.00 0.60 0.71 0.82 1.00 0.52 0.62 0.73 0.83 0.33 0.43 0.53 0.63
PI 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53 1.53
10
TC 7.47 7.55 7.64 7.73 7.89 7.89 7.89 7.98 8.11 8.11 8.11 8.11 8.70 8.70 8.70 8.70
S/T 0.77 0.88 1.00 1.00 0.60 0.71 0.82 1.00 0.52 0.62 0.73 0.83 0.34 0.44 0.53 0.63
PI 1.56 1.56 1.56 1.56 1.55 1.55 1.55 1.55 1.55 1.55 1.55 1.55 1.55 1.55 1.55 1.55
15
TC 7.40 7.49 7.58 7.67 7.83 7.83 7.83 7.92 8.06 8.06 8.06 8.06 8.66 8.66 8.66 8.66
S/T 0.78 0.89 1.00 1.00 0.61 0.72 0.83 0.93 0.53 0.63 0.74 0.84 0.34 0.44 0.54 0.64
PI 1.59 1.59 1.59 1.59 1.59 1.59 1.59 1.59 1.59 1.59 1.59 1.59 1.58 1.58 1.58 1.58
20
TC 7.32 7.41 7.49 7.58 7.75 7.75 7.75 7.84 7.98 7.98 7.98 7.98 8.58 8.58 8.58 8.58
S/T 0.78 0.89 1.00 1.00 0.61 0.72 0.83 0.93 0.53 0.63 0.74 0.84 0.34 0.44 0.54 0.64
PI 1.65 1.65 1.65 1.65 1.64 1.64 1.64 1.64 1.64 1.64 1.64 1.64 1.63 1.63 1.63 1.63
25
TC 6.98 7.03 7.09 7.15 7.41 7.41 7.41 7.49 7.64 7.64 7.64 7.64 8.21 8.21 8.21 8.21
S/T 0.80 0.92 1.00 1.00 0.62 0.73 0.84 0.95 0.53 0.64 0.75 0.86 0.34 0.44 0.54 0.65
PI 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82 1.82
30
TC 6.63 6.69 6.75 6.80 7.06 7.06 7.06 7.12 7.29 7.29 7.29 7.29 7.84 7.84 7.84 7.84
S/T 0.82 0.94 1.00 1.00 0.63 0.74 0.86 0.98 0.54 0.65 0.77 0.88 0.34 0.44 0.55 0.66
PI 1.98 1.98 1.98 1.98 1.99 1.99 1.99 1.99 1.99 1.99 1.99 1.99 2.00 2.00 2.00 2.00
35
TC 6.32 6.37 6.43 6.49 6.72 6.72 6.72 6.78 6.92 6.92 7.03 7.09 7.46 7.46 7.46 7.46
S/T 0.83 0.96 1.00 1.00 0.63 0.76 0.88 1.00 0.54 0.66 0.78 0.89 0.33 0.45 0.56 0.67
PI 2.17 2.17 2.17 2.17 2.18 2.18 2.18 2.18 2.19 2.19 2.19 2.19 2.20 2.20 2.20 2.20
40
TC 5.96 6.02 6.08 6.13 6.35 6.35 6.38 6.43 6.54 6.54 6.60 6.66 7.07 7.07 7.07 7.07
S/T 0.87 1.00 1.00 1.00 0.65 0.79 0.92 1.00 0.55 0.69 0.82 0.95 0.33 0.45 0.57 0.90
PI 2.40 2.40 2.40 2.40 2.41 2.41 2.41 2.41 2.42 2.42 2.42 2.42 2.43 2.43 2.43 2.43
46
TC 5.52 5.58 5.64 5.69 5.90 5.90 5.95 6.01 6.07 6.07 6.07 6.13 6.59 6.59 6.59 6.59
S/T 0.88 1.00 1.00 1.00 0.66 0.80 0.94 1.00 0.56 0.70 0.84 0.97 0.33 0.45 0.58 0.92
PI 2.67 2.67 2.67 2.67 2.68 2.68 2.68 2.68 2.69 2.69 2.69 2.69 2.71 2.71 2.71 2.71
50
TC 5.18 5.23 5.29 5.35 5.52 5.52 5.58 5.64 5.72 5.72 5.72 5.78 6.18 6.18 6.18 6.18
S/T 0.91 1.00 1.00 1.00 0.68 0.83 0.97 1.00 0.57 0.71 0.86 1.00 0.32 0.46 0.59 0.97
PI 2.89 2.89 2.89 2.89 2.91 2.91 2.91 2.91 2.91 2.91 2.91 2.91 2.94 2.94 2.94 2.94
TC:Total Cooling Capacity (kW)
S/T:Sensible Cooling Capacity Ratio
PI:Power Input(kW)
Note: The table shows the case where the operation frequency of a compressor is fixed.
