CLIVET DUCT-SL 2 Series - 7.1 Heating Capacity Tables

Specifications
 Page 52 
7.1 Heating
ID2-XY 35M+MC2-Y 35M
HEATING PERFORMANCE AT INDOOR DRY BULB TEMPERATURE
INDOOR
AIRFLOW (CMH)
OUTDOOR
DB(°C)
TC:TOTAL CAPACITY IN KILOWATTS (KW) PI:TOTAL POWER IN KILOWATTS (KW)
Indoor Conditions (DB °C ) Indoor Conditions (DB °C )
16.0 20.0 22.0 24.0 16.0 20.0 22.0 24.0
300
-15.0 3.59 3.57 3.54 3.51 1.58 1.64 1.59 1.59
-10.0 3.84 3.81 3.78 3.75 1.68 1.75 1.69 1.69
-7.0 4.02 3.99 3.96 3.93 1.79 1.86 1.80 1.80
-5.6 3.96 3.93 3.90 3.87 1.72 1.72 1.72 1.72
-2.8 3.87 3.84 3.81 3.81 1.59 1.59 1.58 1.58
0.0 3.76 3.73 3.70 3.67 1.46 1.45 1.45 1.44
2.8 3.76 3.73 3.70 3.67 1.35 1.34 1.33 1.32
5.6 3.90 3.84 3.81 3.78 1.24 1.21 1.20 1.19
7.0 4.05 3.99 3.99 3.96 1.18 1.08 1.14 1.12
11.1 4.04 4.02 3.99 3.96 0.99 0.96 0.94 0.92
13.9 4.07 4.02 3.99 3.96 0.87 0.83 0.81 0.79
16.7 4.07 4.02 3.99 3.93 0.74 0.70 0.67 0.65
18.0 4.07 4.02 3.96 3.93 0.68 0.64 0.61 0.59
480
-15.0 3.67 3.65 3.62 3.59 1.60 1.66 1.61 1.61
-10.0 3.92 3.89 3.86 3.84 1.70 1.77 1.71 1.71
-7.0 4.11 4.08 4.05 4.02 1.81 1.88 1.82 1.82
-5.6 4.05 4.02 3.99 3.96 1.74 1.74 1.74 1.74
-2.8 3.96 3.93 3.90 3.87 1.61 1.60 1.60 1.60
0.0 3.84 3.81 3.78 3.76 1.48 1.47 1.46 1.45
2.8 3.84 3.81 3.78 3.76 1.36 1.35 1.34 1.33
5.6 3.99 3.93 3.90 3.87 1.25 1.22 1.21 1.20
7.0 4.13 4.07 4.07 4.04 1.19 1.09 1.15 1.14
11.1 4.16 4.10 4.07 4.04 1.00 0.97 0.95 0.93
13.9 4.16 4.10 4.07 4.02 0.88 0.83 0.81 0.79
16.7 4.16 4.10 4.04 4.02 0.75 0.70 0.68 0.66
18.0 4.16 4.10 4.04 4.02 0.69 0.64 0.62 0.59
600
-15.0 3.70 3.67 3.64 3.62 1.61 1.68 1.62 1.62
-10.0 3.95 3.92 3.89 3.86 1.72 1.79 1.73 1.73
-7.0 4.13 4.11 4.08 4.05 1.83 1.90 1.84 1.84
-5.6 4.08 4.05 4.02 3.99 1.76 1.76 1.76 1.76
-2.8 3.99 3.96 3.93 3.90 1.63 1.62 1.62 1.61
0.0 3.87 3.84 3.81 3.78 1.49 1.48 1.48 1.47
2.8 3.87 3.84 3.81 3.78 1.37 1.36 1.36 1.35
5.6 4.02 3.96 3.93 3.90 1.26 1.24 1.22 1.21
7.0 4.16 4.10 4.10 4.07 1.20 1.10 1.16 1.15
11.1 4.19 4.13 4.10 4.07 1.01 0.97 0.96 0.94
13.9 4.19 4.13 4.10 4.04 0.88 0.84 0.82 0.80
16.7 4.19 4.13 4.07 4.04 0.76 0.71 0.68 0.66
18.0 4.19 4.13 4.07 4.04 0.69 0.64 0.62 0.59
Note: The table shows the case where the operation frequency of a compressor is fixed.
