CLIVET ELFODuct MP Series User Manual

 &MGPEVDU.5
13.5 4-pipe system
Size 15 21 31 41 51 61
Cooling
Cooling capacity 1 kW 5.83 7.22 9.96 12.4 13.2 16.6
Sensible capacity 1 kW 4.42 5.35 7.83 9.53 10.4 12.8
Total power input 1 kW 0.16 0.16 0.31 0.31 0.46 0.46
Heating
Heating capacity 2 kW 6.61 6.97 11.6 12.2 15.5 16.4
Total power input kW 0.16 0.16 0.31 0.31 0.46 0.46
Internal exchanger
Number of rows No 3 + 1 3 + 1 3 + 1 3 + 1 3 + 1 3 + 1
Water content l 1,9 + 0,6 2,0 + 0,6 2,9 + 0,9 3,0 + 0,9 3,9 + 1,2 4,0 + 1,2
Water ow-rate 1 l/s 0.28 0.35 0.48 0.59 0.63 0.79
Pressure drop 1 kPa 27 35 20 30 13 21
Air Handling Section Fans (Supply)
Type of supply fan 3 CFG CFG CFG CFG CFG CFG
Number of supply fans No 1 12233
Supply airow 4 l/s 292 317 556 603 742 814
Supply airow 4 m3/h 1.050 1.140 2.000 2.170 2.670 2.930
Max. static pressure supply fan Pa 145 150 135 140 130 135
CONNECTIONS
Water ttings 3/4”F
3/4”F 3/4”F 3/4”F 3/4”F 3/4”F
Water ttings 1/2”F 1/2”F 1/2”F 1/2”F 1/2”F 1/2”F
Condensate drain 5 Ø 20 20 20 20 20 20
Power supply
Standard power supply V 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
Noise Levels
Sound pressure level (1 m) 6 dB(A) 53 54 60 61 58 59
Sound power in the duct 6 dB(A) 64 65 71 72 69 70
1. Indoor air temperature at 27°C D.B./19°C W.B.. Water temperature in / out 7°C / 12°C. Air ow at maximum speed (ESP = 0Pa)
2. Indoor air temperature at 20°C. Water temperature inlet/outlet = 70°C / 60°C. Air ow at maximum speed - Free outlet unit
(ESP = 0Pa)
3. CFG = AC centrifugal fan
4. Air ow at maximum speed (ESP = 0Pa)
5. Intended as an external diameter
6. The sound levels refer to ceiling units without false ceiling, with nominal air ow, fan supply 220V, at maximum speed. Sound
pressure levels referred to 1 m. from unit external surface.
13.6 Operating range
Size 15 21 31 41 51 61
Heating
Max inlet water temperature [°C] 100 100 100 100 100 100
Min. entering water temperature [°C] 333333
Max. inlet air temperature (D.B.) [°C] 40 40 40 40 40 40
Min entering air temperature (D.B.) [°C] 222222
Cooling
Max. inlet air temperature (D.B.) [°C] 40 40 40 40 40 40
Min entering air temperature (D.B.) [°C] 222222
Maximum water side pressure bar 15 15 15 15 15 15
