CLIVET ELFODuct MP Series User Manual

 &MGPEVDU.5
14 Accessories
Congurations
CC4 Coil conguration for 4-pipe system
Air side features
R3 Floor air inlet
RP rear intake
RF Front air inlet
SFCF Air lter section (ductable) with EU3 at air lter (Eurovent 4/5)
SFHEX Air lter section (ductable) with EU5 air lter (Eurovent 4/5)
FAPS EU3 at air lter (Eurovent 4/5) not ductable
CUFMX Air outlet casing with bird-proof grill
CUFAX Air intake casing with bird-proof grill and EU3 air lter (Eurovent 4/5)
PCCMAX Section with spigots “Ø” with variable diameter and internal insulation for both air intake / supply outlets
P90MAX 90° section for both air intake / supply outlets
VEC High eciency EC fan
SILMAX Labyrinth noise level attenuator section for both air intake / supply outlets
MCRX Mixing and recirculating chamber
PMAX Straight section for both air intake / supply outlets
PGFMAX Anti-vibration section for both air intake / supply outlets
Water circuit
3V2 Three-way valve kit for 2-pipe type “on/o” system
3V4 Three-way valve kit for 4-pipe system type “on/o”
10V2 0-10V 3-way valve kit for 2-pipe system
10V4 0-10V 3 way valve kit for 4-pipe system
2V2 ON/OFF 2 way valve kit for 2-pipe system
2V4 ON/OFF 2 way valve kit for 4-pipe system
BRV Auxiliary condensate collection pan (vertical installation)
BRO Auxiliary drain pan in galvanized steel with thermal insulation
Electric Circuit
CTSP1 CLIVET TALK TERMINAL SPACE electronics with RS485 Modbus serial port
CPVM Control additional card of 0-10V valve
TRM Terminal block with minimum water temperature clickson
TRP Terminal block with closing cover IP40
TRMP Terminal block with closing cover IP40 and minimum water temperature clickson
HIDE2X Remote control with E/I +3V +on/o for wall installation
HIDE3X Plurifunctional remote control for wall installation
HIDE4X Plurifunctional room control for 0-10V valves
HIDT2X HID-T2 electronic room control
HIDT3X HID-T3 electronic room control
HIDTI2X HID-TI2 Flush-mounted electronic room control
DCPX Control device for more units with a single room control.
EH230X Heating section with electrical haters 230V with safety thermostat
EH400X Heating section with electrical haters 400V with safety thermostat
PTABX Remote probe for room air temperature for electromechanical thermostats.
X - When the letter X is placed at the end, this means that the accessory is supplied separately. If there is no X in the code, the accessory is mounted in the
factory.
