2.4.8 Derived ducts
These units can be fitted with small ducts for air conditioning a small room nearby.
The units are designed for ducting on all 4 sides.
Service hole for
draining pump
E-parts box
Liquid side
Gas side
Body
4-install hanger
Fig. 36
l
WARNING
Limit the length of the ducts to 2m, 1m each
if ducts are connected to 2 sides.
